Economical Acoustic Baffle Ceiling Roll Forming Machine
Video About This Machine→
Products Description
KINGREAL MACHINERY is one of the professional rolls forming
machine manufacturer in China and we have a lot of experience.
We can provide different kinds of U baffle ceiling making machine.
In order to meet the needs of different customers, in addition to
producing different heights baffle ceiling of roll forming machine,
KINGREAL also specially designed an economical baffle ceiling production line.
On the premise of not affecting the production capacity, this production line simplifies
part of the equipment, which can minimize the budget and obtain more benefits for customers.
Main Components
Hydraulic Decoiler
Roll Forming Machine
Follwing Shearing System
Reference Date
|
Raw materials |
Pre-painted Aluminum or Pre-painted Galvanized steel |
|
Raw materials thickness |
Pre-painted aluminm: 0.5-1.2mm, PPGI strips: 0.5-0.8mm, raw materials thickness need to be increased as the U baffle ceiling sizes increased |
|
Product sizes |
Height: 25-200mm, width 35-1000mm |
|
Uncoiler |
Manual loading and hydraulic expanding, max bearing weight about 5 tons, coil trolley can be equipped if requested |
|
Precision straightener |
21 rollers high precision straightener to ensure the final products smoothness and straightness. |
|
Width and height adjustable |
Automatic servo control, two servo motor to control the width and one to control the height, auto setting, only need to input the requested products length and width on the touch screen. |
|
Maximum forming speed |
35 m / min, adjustable for different sizes and thickness baffles strips. |
|
Roll Forming stands |
14 Rollers station |
|
Driving method |
The rollers stations are drive by the reduce motor. |
|
Machine Power |
~ 30KW |
Other available types Machine
300MM U Baffle Ceiling Roll Forming Machine
why choose our products
KINGREAL 300MM U Baffle Ceiling Forming Machine is a machine specifically designed for the manufacture of U-shaped baffle ceilings. Capable of producing U-shaped baffles up to 300mm high and 1.5mm thick, the machine is typically used for high-end architectural finishes on projects for clients such as the Hunter Douglas Group.
Features of the machine include:
1. A unique hollow roller design that reduces indentation problems due to the weight of the rollers and is particularly suited to the production of U-shaped baffle in excess of 200mm in height.
2. High-speed following shear system to ensure the continuous working of the whole production line. Usually driven by a high-precision servo feeder, connected to a planetary gearbox, which drives the cutter via a timing belt.
3. the hydraulic part of the cutter is pressurized to ensure fast action and reset.
150MM Simple Baffle Ceiling Machine
why choose our products
150MM Baffle Ceiling Roll Forming Machine is specially designed by KINGREAL to produce BAFFLE CEILING products of 150MM height and 30-100MM width.
The economical design minimizes the manufacturing cost of the machine, which can save the cost for customers and get higher economic benefits.
acoustic baffle ceiling
The choice for material is also abundant. Aluminum, Gi Steel or Acoustic materials are available. But please be careful when changing to materials with different thicknesses will require a thorough manual adjusting for production line.
Machine Quality Assurance
the final view of project
Lorem ipsum dolor sit, amet consectetur adipisicing elit.
KINGREAL has established a strict quality control process to ensure that every production step meets the standards and requirements. This includes raw material procurement, production process, assembly, testing, etc. To ensure that every part of the machine meets quality standards.
It has also passed the international CE certificate certification.
---------------------------------------------------------------------Packing and Shipping----------------------------------------------------------------------
(Click Here To Our Related Project Introduction)
---------------------------------------------------------------------Professional Team----------------------------------------------------------------------
KINGREAL ROLL FOMER has its own professional technical team. With strong professional ability and rich design experience, KINGREAL ROLL FORMER engineers can design machines according to the drawings provided by customers and the corresponding production needs. Solve all technical problems during the production, installation and use of the machine.
