Different Type Volume Control Damper Frame Roll Forming Machine
Video About VCD Frame Roll Forming Machine
Description Of VCD Frame Roll Forming Machine
KINGREAL ROLL FORMER VCD Frame Roll Forming Machine is an advanced automatic machine specially designed to produce VCD frame quickly and efficiently. Manufactured with advanced technology and high quality materials, this machine has stable performance and long life to meet various production requirements.
According to the different production needs of customers and different types of VCD frame, KINGREAL ROLL FORMER has designed and developed three different production solutions for customers to choose from.
2. Full Auto Roll Forming Machine And Manual Bending Machine
3. Fire Damper Blades making machine
Working Process Of VCD Frame Roll Forming Machine
Hydraulic Decoiler -- Precision Straightener -- Hole Punching System -- Main Roll Forming Machine -- Hydraulic Bending Cutting Station -- Output Table
Technical Specification of VCD Frame Roll Forming Machine
|
Machine Name |
VCD Frame Making Equipment |
|
Products Name |
Volume Control Damper |
|
Brand |
KINGREAL |
|
Automation |
Manual Operation/Full-Automatic Production with PLC |
|
Raw material |
GI steel Thickness: 0.8-2.5mm |
|
Coil weight |
≤3000kg |
|
Line speed |
1-15m/min (adjustable) |
|
Length tolerance |
±0.3mm/1000mm |
|
Punching hole distance tolerance |
±0.3mm/1000mm |
|
Min frame sizes |
120*120mm |
|
Profile Flange |
Fixed width 150 mm (VCD Flange 35mm) |
|
Processing method |
cut To length / single straight piece / 口 type / L type |
|
Control mode |
PLC control |
|
Total power |
about 31KW |
We offer full solution for the ventilation system machines, which includes:
- Volume control damper frame making machine
- Fire damper frame making machine
- Square smoke damper making machine
- Air regulating damper making machine
- Non-return damper making machine
- Back-draft damper making machine
Customized VCD Frame Roll Forming Machine
KINGREAL Roll Former VCD damper frame machines are custom-designed entirely based on the specific project requirements of our clients-including the dimensions, type, and shape of the damper frames. KINGREAL Roll Former standard range of VCD damper frame machines is capable of meeting client production needs for various components, such as the damper frames for volume control damper, fire damper frame, and smoke damper frame.
Application Of VCD Frame
Volume Control Damper Frame Machine is widely used in are conditioning and ventilation system industries to produce various specifications and models of damper frames.
The machine can meet the demand of producing dampers frame with different specifications and shapes, and is suitable for large-scale factories and small-scale production line.
Why Choose Us?
1. Who Are We?
KINGREAL ROLL FORMER is a professional sheet metal processing machines manufacturer and supplier.
We offer full automatic and high speed solutions mainly including roll forming machines, metal ceiling tile machines, metal perforation line, coil slitting lines, etc.
KINGREAL ROLL FORMER had helped our clients to build their factories successfully all over the world, such as Russia, Middle East, South Asia, South America, etc.
2. Our Feature Product
KINGREAL ROLL FORMER has been specializing in the field of molding machines for more than 20 years and has experience in the production and design of a wide range of machines to provide customers with complete production solutions.
3. Our Exhibition
