Fire Damper Making Machine
Video About Fire Damper Making Machine
Fire Damper Making Machine Desription
|
KINGREAL ROLL FORMER has rich experience and technical means in the development and production of automatic Fire/ Damper Frame Production Lines of the fire damper. The line is controlled by the PLC computer system, including the material decoiler, leveling and beading, punching, roll forming and auto bending forming.
The fastest linear speed is 13m/min, which is suitable for the production of various valve fire damper frames. With the fire damper blade forming machine and the fire damper multi-function riveting platform, a fully automatic workshop is formed, which greatly reduces labor costs.
|
 |
 |
This fire damper frame equipment can produce two types of frame products, a new type of integrated hand-folding frame, and a TDF corner code connection riveting frame, which can be produced by high-efficiency application of new technology, and can also meet the production of old technology.
To meet different production damands. The fire damper frame production line has unique structure and design including PUNCHING, COLD ROLL FORMING, BENDING FORMING technologies. Integrate these technologies, similar production line can be use to produce fire dampers, smoke dampers, volume control dampers, fire hose cabinet and etc.
This fire damper frame equipment has a formula function: no waste is generated during the production process, saving material costs; different valve body frame sizes can be input at one time, and different numbers of frames can be continuously produced at one time with high production efficiency. Functions include: roll material-leveling-shearing-punching and cutting corners-frame roll forming (two kinds of frames can be formed)-cutting-(one-piece manual folding)-riveted frame bending
|
Technical Specification Of Fire Cabinet Making Machine
|
Equipment occupying space |
20×3×2 (length × width × height) meters |
|
Weight |
26 tons |
|
Raw Material specification |
Q235 |
|
Electric control |
Mitsubishi PLC |
|
Unloader load capacity |
5 tons |
|
Forming frame |
15-18 passes (according to different shapes) |
|
Leveling and feeding |
nine-rollers leveling |
|
Cut-off size tolerance |
≤ ±0.5mm |
|
Production speed |
0-12m/min |
Fire Damper Frame Machine Structure
- 1. One material rack
- 2. One set of leveling, punching and shearing machine
- 3. One set of fire damper frame roll forming machine
- 4. Six sets of blanking dies
- 5. One set of workbenches
- 6. One folding shearing machine
- 7. A set of control system
Fire Damper Making Machine Features
Strong Roll Forming Machine Structure
KINGREAL ROLL FORMER machine frame is welded by steel panel to one-piece structure. Then one 30mm thickness panel will be put on the frame after fine processed by the Plano miller.
This will ensure the accuracy basic size. Also, it will increase the machine strength to reduce the deformation and ensure the long-life time operation.
Online Punch system
KINGREAL ROLL FORMER use high-speed punching machines, hydraulic punching machines, etc. for online punching of products. After punching, the product can directly enter the roll forming machine for cold bending forming.
Our punching machine has the characteristics of fast punching speed, high precision and strong stability.
Our Advantages
Rich Projects experiences
Our company has rich experience in design, production and installation of roll forming machines. At present, our company has completed designing and producing of more than 500 kinds of different forming machines. We've been successfully exported and installed our machines in more than 60 countries around the world and won joint praise of customers.
Relying on rich project experiences and customer feedback, we continue to improve, innovate, and be dedicated to produce faster, smarter,more automatic and efficient machines.
Overall solution including punching, bending, forming, welding, etc.
Our company can provide a overall solution according to customer needs, including product punching, automatic forming, bending, welding, etc.
This solution is widely used in full automatic production of various complex profiles, such as closed complex profiles, shelf columns, etc.
Product Display
Our Customers
Local After-Sale Service
